pastax

Parameterizable Auto-differentiable Simulators for ocean surface Trajectories in jAX.

pastax integrates particle trajectories on the ocean surface by solving ODEs and SDEs over user-supplied forcing fields (e.g. surface currents). Every computation is fully differentiable via JAX automatic differentiation — both forward-mode (jax.jvp) and reverse-mode (jax.grad) are supported (forward-mode requires solve(..., adjoint="forward"); the default checkpointed adjoint is reverse-mode only).

📖 Documentation: https://vadmbertr.github.io/pastax/ — full API reference and a runnable tutorial notebook.

Project Status

Installation

From Git:

pip install git+https://github.com/vadmbertr/pastax             # core (JAX, Equinox, jaxtyping)
pip install "git+https://github.com/vadmbertr/pastax[forcing]"  # + xarray, zarr, netCDF4

From source:

git clone https://github.com/vadmbertr/pastax
cd pastax
pip install -e ".[dev]"

Installing a JAX GPU version should be done prior to installing pastax, following https://docs.jax.dev/en/latest/installation.html.

Quick Start

ODE and SDE simulation

The term signature is term(t, y[, args, ctrl]). The optional args argument is present when args is passed to solve. The optional ctrl argument is present when controls is passed to solve — the solver slices controls[i] at each step and forwards it. The term owns all interpretation of args and ctrl.

t0 is a traced JAX scalar — changing it never triggers recompilation. n_save, int_dt, and save_dt are static Python scalars; the end time is implicit as t0 + n_save * save_dt. Sub-stepping is expressed by setting int_dt < save_dt with save_dt / int_dt an integer.

Without key passed to solve it is ODE mode and the term returns a velocity; with key it is SDE mode and the term returns (drift, g).

import jax.numpy as jnp
import jax.random as jr
from pastax import solve, Heun, RK4, EulerHeun, meters_to_degrees

# --- ODE term (no key) ---
def ode_term(t, y, args):
    dataset = args
    u = dataset["u"].interp(t, y[0], y[1])
    v = dataset["v"].interp(t, y[0], y[1])
    return meters_to_degrees(jnp.array([v, u]), y[0])   # deg/s

y0 = jnp.array([48.0, -4.0])   # [lat, lon]
t0 = jnp.array(0.0)            # start time, seconds
traj = solve(ode_term, y0, t0, n_save=120, int_dt=3600., save_dt=3600., args=dataset)
# shape (121, 2)

# --- ODE term with per-step controls ---
def perturbed_term(t, y, args, ctrl):
    dataset = args
    z = ctrl
    base_vel = ...
    return base_vel + 1e-4 * jnp.tanh(z)

n_fine = 120  # = n_save * round(save_dt / int_dt)
traj = solve(perturbed_term, y0, t0, n_save=120, int_dt=3600., save_dt=3600.,
             args=dataset, controls=jr.normal(jr.key(0), (n_fine, 2)))

# --- SDE term (pass key) ---
def sde_term(t, y, args):
    dataset = args
    u = dataset["u"].interp(t, y[0], y[1])
    v = dataset["v"].interp(t, y[0], y[1])
    drift = meters_to_degrees(jnp.array([v, u]), y[0])
    g     = jnp.full(2, 1e-5)   # diagonal diffusion, deg / sqrt(s)
    return drift, g             # z ~ N(0, I_2) is drawn internally

traj     = solve(sde_term, y0, t0, 120, 3600., 3600., EulerHeun(), args=dataset, key=jr.key(0))
ensemble = solve(sde_term, y0, t0, 120, 3600., 3600., EulerHeun(), args=dataset, key=jr.key(0),
                 n_samples=100)
# shapes: (121, 2) and (100, 121, 2)

In SDE mode the solver draws a standard-normal z and applies dW = sqrt(int_dt) * z internally; the term never sees z. For a flat state g can be shape (2,) (diagonal) or (2, 2) (full matrix). The Euler, Heun, and RK4 solvers accept both ODE and SDE mode; ItoMilstein / StratonovichMilstein give strong order 1.0 for diagonal g via jax.jacfwd.

PyTree state and second-order dynamics

The state y can be any PyTree (a bare array is the single-leaf case). The term returns the time derivative dy with the same structure as y, and the output trajectory is a PyTree shaped like y0 with a leading time axis on each leaf. This makes second-order dynamics natural — dv = f(x, t) dt + noise, dx = v dt — by carrying y = (x, v) and putting the noise on the velocity leaf:

from typing import NamedTuple
import jax.numpy as jnp
import jax.random as jr
from pastax import solve, EulerHeun

class State(NamedTuple):
    x: jnp.ndarray   # position [lat, lon]    (deg)
    v: jnp.ndarray   # velocity [v_lat, v_lon] (deg/s)

def sde_term(t, y):
    accel = -(y.v - u_current(t, y.x)) / tau          # your f(x, t[, v]); deg/s^2
    drift = State(x=y.v, v=accel)                      # dx = v, dv = accel
    diff  = State(x=jnp.zeros(2), v=jnp.full(2, 1e-5)) # diagonal noise on velocity only
    return drift, diff

y0   = State(x=jnp.array([48.0, -4.0]), v=jnp.zeros(2))
traj = solve(sde_term, y0, jnp.array(0.0), 120, 3600., 3600., EulerHeun(), key=jr.key(0))
# traj.x, traj.v each have shape (121, 2)   — underdamped Langevin: dx=v dt, dv=accel dt + g dW

For a general (matrix / cross-leaf) diffusion, return a lineax AbstractLinearOperator as the diffusion (applied via .mv(dW)); pass brownian_structure= (a PyTree of jax.ShapeDtypeStruct) when the noise space differs from the state space. This needs the optional lineax dependency (pip install "pastax[sde]"); the diagonal per-leaf form above needs no extra dependency. The Milstein solvers remain flat array only.

Loading forcing fields from xarray

import xarray as xr
from pastax import Dataset

ds = xr.open_zarr("path/to/currents.zarr")
dataset = Dataset.from_xarray(
    ds,
    fields={"u": "uo", "v": "vo"},
    coordinates={"time": "time", "lat": "latitude", "lon": "longitude"},
)

Or directly from numpy/JAX arrays:

import numpy as np

t   = np.linspace(0.0, 4 * 86400.0, 5)  # seconds
lat = np.linspace(40.0, 50.0, 100)
lon = np.linspace(-10.0, 0.0, 100)
u_data = np.ones((5, 100, 100), dtype=np.float32)

dataset = Dataset.from_arrays({"u": u_data}, t=t, lat=lat, lon=lon)

Loading C-grid forcing (NEMO convention)

For data on an Arakawa C-grid, every vector field has its U component on the east faces of the centre cells (shape (time, nlat, nlon - 1)) and its V component on the north faces (shape (time, nlat - 1, nlon)). Vector fields are declared via the vectors mapping; the outer key is a free-form label for each pair (used in error messages) and the inner tuples give the field names under which the components are registered in Dataset.fields plus their values. from_arrays_cgrid auto-derives the staggered coordinates as half-cell shifts of the centre grid and shares them across every registered vector:

from pastax import Dataset

dataset = Dataset.from_arrays_cgrid(
    t, center_lat, center_lon,
    vectors={
        "current": {"u": ("u", u_values), "v": ("v", v_values)},
    },
    tracers={"sst": sst_values},    # optional, at cell centres (T, nlat, nlon)
)
# dataset["u"].stagger == "u_face"
# dataset["v"].stagger == "v_face"
# dataset.grid.stagger_type == "C"

Several vector fields can live on the same C-grid — surface current and 10-m wind, or a decomposition into geostrophic / Ekman / Stokes components — by adding more entries to vectors:

dataset = Dataset.from_arrays_cgrid(
    t, center_lat, center_lon,
    vectors={
        "current": {"u": ("uo",  u_curr), "v": ("vo",  v_curr)},
        "wind":    {"u": ("u10", u_wind), "v": ("v10", v_wind)},
    },
)
# dataset.fields.keys() == {"uo", "vo", "u10", "v10"}
# Pick the pair to integrate via velocity_interp(u_name=..., v_name=...).

The same term you wrote for A-grid forcing works unchanged — each Field reads its (already-shifted) coordinates from the shared Grid by stagger role, so Field.interp applies the correct bilinear-on-shifted-coords sample at the particle position.

xarray analogue:

dataset = Dataset.from_xarray_cgrid(
    ds,
    vectors={
        "current": {"u": ("u", "uo"), "v": ("v", "vo")},
        # each tuple is (internal_field_name, xarray_variable_name)
    },
    coordinates={"time": "time", "lat": "lat", "lon": "lon"},  # centre coords
    tracers={"sst": "thetao"},
)

Coastal forcing

Real ocean forcing has land. By default the loaders detect land cells automatically:

# u_data has NaN at every land cell (CMEMS / CF convention)
dataset = Dataset.from_arrays({"u": u_data, "v": v_data}, t=t, lat=lat, lon=lon)
# NaN was replaced with 0 in the stored values; a 2-D bool mask
# was inferred from the NaN locations and attached to each Field:
# dataset["u"].mask.shape == (nlat, nlon)

If your data marks land with zeros (NEMO convention) or a custom flag, pass an explicit mask instead:

land_mask = (raw_bathy == 0)               # True where land
dataset = Dataset.from_arrays(
    {"u": u_data, "v": v_data}, t=t, lat=lat, lon=lon,
    masks={"u": land_mask, "v": land_mask},
)

The mask is consumed by Field.interp to switch from naive bilinear to inverse-distance partial-cell weighting whenever a cell straddles the coast: land corners are dropped and the remaining ocean corners are weighted by 1 / d² from the query point. Fully land-bound cells return 0. This eliminates the “stuck particle” artefact that plagues naive bilinear interpolation on A-grid coastal data — particles released near a coast slide along it at the correct ocean velocity instead of stalling.

For richer wall-physics control, use Dataset.velocity_interp to interpolate (U, V) jointly with an opt-in partial-slip correction:

def my_term(t, y, args):
    dataset = args
    vel = dataset.velocity_interp(t, y[0], y[1], scheme="partialslip")
    return meters_to_degrees(vel, y[0])   # vel is [v, u] = [dlat/dt, dlon/dt]

scheme="default" (the default) composes per-field Field.interp (inverse-distance when a mask is present). scheme="partialslip" applies a tunable wall-slip correction near fully-land edges: U near a latitudinal coast is rescaled by (slip_a + slip_b * wl), and V near a longitudinal coast by (slip_a + slip_b * wj). The default slip_a = slip_b = 0.5 gives a half-slip wall; slip_a = 1, slip_b = 0 recovers full free-slip. Partial-slip is A-grid only — calling it on a C-grid dataset raises NotImplementedError.

C-grid forcing handles coasts correctly without any mask, provided U and V at land-adjacent faces are exactly zero (the NEMO output convention): the face-normal velocity then vanishes at the coast by construction.

All three coastal paths (inverse-distance, partial-slip, naive bilinear) are gradient-safe under jax.grad and jax.jvp.

Neighbourhood extraction

# Extract a 5×5×5 patch of raw grid values around a query point
patch = dataset["u"].neighborhood(t, lat, lon, t_window=2, lat_window=2, lon_window=2)
# shape (5, 5, 5)

# Or for all fields at once
patches = dataset.neighborhood(t, lat, lon, lat_window=1, lon_window=1)
# dict[str, Array] with shape (3, 3, 3) per field

Geographic conversions

from pastax import meters_to_degrees, degrees_to_meters

disp_m = jnp.array([1000.0, 500.0])  # [north, east] metres
lat_ref = jnp.array(45.0)
disp_deg = meters_to_degrees(disp_m, lat_ref)   # [dlat, dlon] degrees

Backwards-in-time integration

Pass negative int_dt and save_dt to integrate backwards. All solvers handle this transparently:

y0_end = jnp.array([48.0, -4.0])
backtrack = solve(my_term, y0_end,
                  t0=jnp.array(86400.0 * 5), n_save=120, int_dt=-3600., save_dt=-3600.,
                  solver=RK4(),
                  args=dataset)
# backtrack[-1] is the source position 5 days earlier.

Differentiability

import jax

# Reverse-mode gradient through the ODE solver (default adjoint="checkpointed":
# low-memory binomial checkpointing, O(sqrt(n)) memory by default)
grad = jax.grad(lambda y0: solve(ode_term, y0, t0, n_save, int_dt, save_dt, args=dataset).sum())(y0)

# Forward-mode JVP requires adjoint="forward" (the checkpointed adjoint is reverse-mode only)
traj, tangent = jax.jvp(
    lambda y0: solve(ode_term, y0, t0, n_save, int_dt, save_dt, args=dataset, adjoint="forward"),
    (y0,), (jnp.ones(2),),
)

The solve adjoint argument selects the differentiation strategy: "checkpointed" (default) uses binomial checkpointing for low reverse-mode memory but does not support jax.jvp; "forward" uses a plain jax.lax.scan (no per-step checkpoint), ideal for jax.jvp / jax.jacfwd. The checkpoints argument tunes the memory/recompute tradeoff of the checkpointed adjoint (default None → equinox.internal.scan’s O(sqrt(n)) Stumm–Walther schedule; larger → more memory, less recompute; "all" → checkpoint every step).

Trajectory metrics

from pastax import separation_distance, normalized_separation_distance, liu_index

# Single-trajectory metrics
sep = separation_distance(trajectory, reference)          # (T,), metres
nsd = normalized_separation_distance(trajectory, reference)  # (T,), dimensionless
li  = liu_index(trajectory, reference)                    # (T,), dimensionless

# Ensemble metrics — broadcasting the ensemble leading axis
sep_ens = separation_distance(ensemble, reference)  # (S, T)
li_ens  = liu_index(ensemble, reference)            # (S, T)

Scoring rules

from pastax import dawid_sebastiani, energy_score, squared_error, variogram_score

# Along trajectory scores
ds_ts = dawid_sebastiani(ens, ref, reduce=None)  # (T,)
es_ts = energy_score(ens, ref, reduce=None)  # (T,)
se_ts = squared_error(ens, ref, reduce=None)  # (T,)
vs_ts = variogram_score(ens, ref, reduce=None)  # (T,)

# Final scores
ds_t1 = dawid_sebastiani(ens, ref, reduce="last")  # scalar
es_t1 = energy_score(ens, ref, reduce="last")  # scalar
se_t1 = squared_error(ens, ref, reduce="last")  # scalar
vs_t1 = variogram_score(ens, ref, reduce="last")  # scalar

# Aggregated scores
ds_agg = dawid_sebastiani(ens, ref, reduce="sum")  # scalar
es_agg = energy_score(ens, ref, reduce="sum")  # scalar
se_agg = squared_error(ens, ref, reduce="sum")  # scalar
vs_agg = variogram_score(ens, ref, reduce="sum")  # scalar

# Custom score kernel (relevant for the energy score and the square error only)
es_agg = energy_score(ens, ref, kernel=separation_distance)
se_agg = squared_error(ens, ref, kernel=separation_distance)

API Reference

The full API reference — every public symbol, signature, and docstring — lives on the documentation site: https://vadmbertr.github.io/pastax/api.

Dependencies

License

Apache-2.0
